Ningbo Fenghua Bolong Machinery Manufacturing Co., Ltd. is one of the leading manufacturers and suppliers of laser cutting in China. Please feel free to buy durable laser cutting made in China here from our factory. All customized products are with high quality and competitive price.
Cutting Capabilities
|
Tube Types |
Operations |
Typical Applications |
|
Round, square, rectangular |
Cut-to-length, end profiling |
Suspension arm tubes, shock absorber cylinders |
|
Elliptical, D-shaped, hexagonal |
Perforating, slotting, contour cutting |
Battery pack frames, precision fittings |
|
Angle, channel, U-channel, I-beam |
End beveling, chamfering |
Equipment frames, machinery structures |
|
- |
Intersecting line cuts (tube-to-tube joints) |
Rack structures, guardrails, conveyor frames |
|
- |
Distortion-free end facing for thin-wall tube |
Battery cooling lines, instrument-grade tubing |
Process Specifications
|
Parameter |
Value |
|
Machine Configuration |
High-performance fiber laser tube cutters (dual-cell, parallel operation) |
|
Tube Length Range |
5800mm – 6200mm |
|
Tube Cross-Section Capacity |
Square 16×16 – 120×120mm; Round φ16 – φ120mm |
|
Positioning Accuracy |
±0.05mm |
|
Repeat Positioning Accuracy |
±0.03mm/1000mm |
|
Maximum Traverse Speed |
≤100m/min |
|
Maximum Acceleration |
1.2G |
|
Maximum Chuck Speed |
180 RPM |
|
Chuck Rated Load |
70kg |
|
Residual Tail Length |
≤50mm |
|
Certifications |
IATF 16949, ISO 14001, Hazardous Substance Control |
Performance Highlights
Tail stock under 50mm
A 500mm A-axis travel module lets the cutting head bridge across the front chuck and complete the final cut between front and rear chucks. Result: residual tail drops from the industry norm of 150mm+ to 50mm or less. On a typical 8-hour run processing 6m lengths of φ60×3mm carbon steel tube, that gives you one or two extra good parts off every length.
Fast traverse, fast acceleration
100m/min traverse speed and 1.2G acceleration. On complex parts with 5 to 8 cutting features per piece, fast positioning shaves over 30% off non-cutting travel time. Two cells running in parallel give us flexibility - split high-volume orders across both, or dedicate one cell to prototypes while the other runs production.
180 RPM chuck speed – all circumferential features, one setup
Six evenly spaced features around a 360° circumference index in roughly half the time of a 90 RPM chuck. All features cut in a single setup - no angular errors from re-chucking, no drift part-to-part.
Dual-cell configuration – throughput and uptime
Two cells run independently, backing each other up. If one goes down for maintenance, the other keeps production moving. No single-point failures. Commit one cell to a long run while the other handles quick-turn jobs, or gang them up on a single large order when the schedule demands it. In JIT delivery, that's not a nice-to-have - it's table stakes.
Quality Control
Raw material check
Every tube lot is verified against material certs for grade, cross-section, and surface condition. Straightness and cleanliness are checked before loading - contamination or bowing gets caught before it hits the machine.
01
In-process monitoring
Laser power, focus position, gas pressure, and cutting speed are tracked continuously against established process windows for each material–wall thickness–section profile combination. ±0.05mm positioning accuracy, combined with live monitoring, ensures every cut lands within nominal dimension. Any axis drift beyond threshold triggers an automatic alarm and machine stop.
02
First-article inspection
At the start of every run, the first piece is checked for:
Profile dimensions and hole locations
End squareness and cut-edge condition (dross, HAZ depth)
Angular positioning of circumferential features
No approval, no green light. First-article data is recorded before the run goes to full production.
03
In-line checks
On high-volume runs, we sample at set intervals. OD, wall thickness, and cut squareness are measured with calibrated tools. Tube end profiles are matched back to CAD. Inspections logged every 2 hours.
04
Final lot release
Every lot gets a full dimensional check on all customer-specified critical characteristics. Shipments go out with a complete inspection package - CMM data included - and full traceability back to raw material heat numbers and production dates.
05
Beyond Automotive
Our tube laser capability also applies to:
|
Sector |
Typical Work |
Cutting Requirements |
|
Construction Equipment |
Frame members, end bevels, chamfers |
Bevel cutting, chamfering |
|
Conveyor Systems |
Frame tubes - cut-to-length, perforated |
Cut-off, wall perforation |
|
Furniture / Commercial |
Shaped metal tube frames - contour cuts |
Slotting, cut-off on elliptical/D-section tube |
|
Energy / Battery |
Frame profiles, intersecting holes |
Custom contouring, line cutting |
|
Instrumentation |
Thin-wall stainless tube - precision end facing |
Distortion-free end cuts on thin-wall tube |
Whether you're in automotive or adjacent industries, the same precision, same material yield, same documentation standards apply.
